Introduction
A heavy-duty valve utilizing internal spring tension to force a fail-safe closure during air loss, providing physical-level protection for industrial pipelines.
Specification
| Medium Temperature | -10 ~ +180℃ |
| Ambient Temperature | -10 ~ +60℃ |
| Control Gas | Neutral Gas and Air |
| Nominal Pressure | 1.6MPa |
| Air Pressure | 0.4 ~ 0.8 MPa |
| Seal Material | PTFE |
Field Performance
HVOF-hardened gate plates significantly extend service life against the intense scouring of tailings and ash.
Integrated discharge grooves and self-cleaning geometry minimize the risk of sealing failure due to material accumulation.
Corrosion-resistant cylinder seals maintain reliable response times even in highly acidic or humid industrial settings.
Manufacturing Excellence & Reliability
High-Precision Machining: Critical sealing faces are ground on 5-axis CNC centers to maintain tolerances within ±0.02mm.
100% Pressure Testing: Every unit undergoes hydrostatic shell tests and low-pressure air leakage tests per API 598.
Functional Safety: Spring configurations are verified through stress relaxation modeling to meet SIL3 Safety Integrity Level requirements.
Application
Mining & Tailings
Preventing premature seat failure in concentrate slurry transport pipelines due to high-concentration solids.
Coal-Fired Power
Critical fail-safe isolation for fly ash and bottom ash handling systems.
Fine Chemicals
Automatic barriers for powder processing lines where power loss presents an explosion or overflow risk.
Metallurgy & Cement
Reliable sealing for high-frequency cycling in raw meal and coal dust injection systems.
Compliance & Credential Transparency
Material Traceability: EN 10204 3.1 Material Test Reports (MTR) are provided for all pressure-containing components.
Regulatory Certification: Full compliance with EU CE-PED directives and ISO 9001:2015 quality management standards.
Structural Validation: FEA (Finite Element Analysis) verified design life exceeding 100,000 full-stroke cycles.
Engineering Support & Logistics
Maintenance Protocols
Preventive maintenance schedules and spring fatigue monitoring manuals provided with every shipment.
Global Logistics
Core consumables (seals and gaskets) are available for 48-hour global dispatch upon request.
Expert Consultation
Sizing calculations and torque safety margin assessments provided by senior fluid control engineer.
FAQ
Q1: How do you guarantee the spring will not suffer from fatigue or fracture over time?
A: We use shot-peened 60Si2Mn spring steel designed at only 65% of its yield limit, ensuring less than 3% performance decay after 1 million cycles.
Q2: What is the specific advantage of your hardening process for high-abrasion media?
A: Unlike standard hard chrome plating, our HVOF process creates a bond strength >70MPa, preventing delamination even under the impact of large, sharp particles.
Q3: Does the valve risk jamming during the fail-safe reset due to internal friction?
A: No. The valve is fitted with low-friction PTFE guides, and the spring reset force is calculated with a minimum 1.3x safety factor over the maximum frictional load.
Q4: Can this valve withstand harsh coastal environments with high salt spray?
A: Yes. Cylinders feature high-corrosion fluorocarbon coatings, and all external fasteners are SS304 as standard, providing IP65-rated protection.
